Classical Ogee Stacked Rail and Stile 1/2" Shank Router Bit
Product Parameters
Description
The Stacked Rail and Stile Router Bit will cut both the profile and cope for rail and stile cabinet doors with a single bit. Simply, cut the profiles with the middle and lower blades and then lower the bit in your table to make the cope cut using the middle and upper blades. No need to switch or reassemble cutters. This bit comes equipped with a radial ball bearing for easy cutting depth setup.
This classical ogee bit can cut stock up to 7/8" and will cut a depth of 3/8". The slots are 1/4" thick and the shank diameter is 1/2".
Bit Specs
Minimum Stock Thickness:3/4"
Maximum Stock Thickness:7/8"
Material:Carbide Tipped
Shank Size:1/2"
Cutting Depth:3/8"
Overall Length:3-5/16"
Largest Diameter:1-5/8"
Number of Flutes:2
Number of Bits:1
Inquiry This Product Now
Frequently Asked Questions
It is suitable for hardwood, softwood, plywood, MDF, and many laminated boards. Always make a test cut first to confirm feed speed and edge quality.
Yes. Custom diameter, shank size, coating, laser marking, packaging, and OEM branding can be discussed based on your drawing or sample.
It can be used in suitable router tables, CNC routers, and compatible woodworking routing setups. Please confirm shank size, machine speed, and fixture stability before production.
Send the product model, quantity, target market, packaging requirements, and any custom specifications to our sales team for a detailed quotation.
Yes. Private label packaging, logo marking, labels, and custom packing plans are available for distributors and tool brands.
