Groove Router Bits

3/16" Hex Bolt T Slot 1/4" Shank Router Bit

Amanda Online Need help? Chat with us

Product Parameters

Description

T-slot router bits are great for creating T-channels for jig and clamp applications and keyholes for hanging projects. It is recommended that a straight groove, matching width to the upper part of the "T", be cut into the workpiece prior to routing the T-slot to reduce the stress on the bit. T-slot cuts produce a lot of wood chips with little room for them to escape and can cause the bit to get bogged down. Go easy on the feed and back off every couple of inches before resuming with the cut.

This t-slot router bit cuts slots for standard 3/16" bolts that have a 3/8" wide x 3/16" high heads with up to 3/16" shaft diameter. The shank is 1/4" in diameter.

Bit Specs
Material:Carbide Tipped
Overall Length:1-15/16"
Largest Diameter:25/64"
Number of Flutes:2
Number of Bits:1
Shank Size:1/4"
Cutting Diameter:25/64"
Cutting Length:7/16"

Inquiry This Product Now

You May Also Like

Flush Trim Template Router Bit Set

45° V Groove Flat Bottom 1/2" Shank Router Bit

See Details
Flush Trim Template Router Bit Set

5/8" Diameter Core Box 1/4" Shank Router Bit

See Details
Flush Trim Template Router Bit Set

Core Box 1/2"W X 1"H 1/4" Shank Router Bit

See Details
Flush Trim Template Router Bit Set

3/4" Diameter Core Box 1/2" Shank Router Bit

See Details

Frequently Asked Questions

It is suitable for hardwood, softwood, plywood, MDF, and many laminated boards. Always make a test cut first to confirm feed speed and edge quality.

Yes. Custom diameter, shank size, coating, laser marking, packaging, and OEM branding can be discussed based on your drawing or sample.

It can be used in suitable router tables, CNC routers, and compatible woodworking routing setups. Please confirm shank size, machine speed, and fixture stability before production.

Send the product model, quantity, target market, packaging requirements, and any custom specifications to our sales team for a detailed quotation.

Yes. Private label packaging, logo marking, labels, and custom packing plans are available for distributors and tool brands.
